Chartpak Pickett Ellipses Templates

Description

Chartpak Templates are made from durable matte finish grey plastic Indespensible when creating accurate to scale layouts This template guide is suitable for use with technical pen or pencil Precisionengraved apertures ensure singlestroke accuracy Matte finish reduces glare Ink risers facilitate clean smudgefree inking and easy pick up/repositioning Made with partially recycled plastic materials## 1266i Isometric Master EllipseTemplate contains ellipses at 25° 35°16 45° and 60° projections in sizes ranging from 1/4 to 11/2 It measures 5 × 11## 1267i Master Ellipse Maker (20° to 50°)Template includes ellipses at 20° 30° 40° and 50° projections in sizes ranging from 1/4 to 11/2 It measures 5 × 11## 1269i Combo Ellipse MasterTemplate includes ellipses at 15° 30° 45° and 60° projections in sizes ranging from 1/8 to 15/8It measures 83/4 × 12## 1264i Isometric EllipseTemplate contains ellipses of 35°16 projections in sizes ranging from 1/8 to 2 It measures 6 × 10## 1262i 4in11 EllipseTemplate features ellipses at 15° 30° 45° and 60° projections in sizes ranging from 5/16 to 21/4 It measures 83/4 × 12
